DESCRIPTION

Karcher iGloss 20 Polishing Machine offers an advanced stand‑on design for enhanced burnishing speed and quality, making it ideal for high‑traffic and compact areas. Featuring a 20″, 2000 RPM pad driver and delivering the industry’s lowest noise levels, it provides brilliant gloss performance while simplifying operation and maintenance — all without compromising results.

KEY APPLICATIONS

• Types of Environments:
   ▪ Commercial spaces
   ▪ Hotels
   ▪ Healthcare facilities
   ▪ Educational institutions

• Floor Types:
   ▪ Hard floors
   ▪ Carpeted areas requiring high‑quality shine

• Places:
   ▪ Corridors
   ▪ Lobbies
   ▪ High‑traffic zones

FEATURES

• Stand‑On Design:
   ▪ Increases productivity and delivers unmatched cleaning quality

• Compact Footprint:
   ▪ Maneuvers easily in tight or busy areas without disrupting workflow

• High‑Speed Pad Driver:
   ▪ 20″, 2000 RPM driver for excellent gloss performance

• Low Noise Level:
   ▪ Industry‑leading quiet operation enables daytime use in noise‑sensitive spaces

• Dust Collection:
   ▪ Disposable dust bag improves indoor air quality

• Spring‑Loaded Weighted Pad:
   ▪ Self‑adjusting pad ensures consistent, maintenance‑free operation

• User‑Friendly Controls:
   ▪ Intuitive presets simplify training and guarantee consistent results

• On‑Board Charger:
   ▪ Charges from any standard outlet (AGM models)

• Safety Features:
   ▪ Tie‑down bar for secure transport and enhanced operator visibility



• Included Accessories:
   ▪ 20″ high‑speed pad driver
   ▪ Disposable dust collection bag
   ▪ Integrated on‑board charger

TECHNICAL SPECIFICATIONS

• Electrical & Performance:
   ▪ Nominal Power: Passive Dust Control 2232 W; Active Dust Control 2628 W
   ▪ Rated Voltage: 36 V DC
   ▪ Rated Amperage: Passive 62 A; Active 73 A



• Motor & Filtration:
   ▪ Burnisher Motor: 3.0 HP, 36 V, 2000 RPM (2237 W)
   ▪ Vacuum Motor: 0.63 HP (470 W) — Max Flow 72 cfm (34 l/s); Max Suction 47.3 in H₂O (11.7 kPa)
   ▪ Propelling Motor: 0.38 HP (280 W)



• Capacity & Construction:
   ▪ GVW: 838 lbs (380 kg)
   ▪ Weight (empty): 231 lbs (105 kg)
   ▪ Burnisher Pad Diameter: 20″ (508 mm)
   ▪ Tires: 8″ drive (203 mm); 6″ rear (156 mm), polyurethane



• Mobility & Safety:
   ▪ Maximum Speed: 2.3 mph (3.7 km/h)
   ▪ Brake: Automatic electrical parking brake
   ▪ Minimum Aisle U‑Turn Width: 51″ (1295 mm)
   ▪ Max Climb/Descent Angle: 10% (6°)
   ▪ Vibration: Hands 1.58 m/s²; Feet 1.39 m/s² (±0.5 m/s²)



• Sound & Acoustics:
   ▪ Sound Pressure Level: Passive 59.7 dB(A); Active 62.2 dB(A)
   ▪ Sound Power Level: Passive 76.3 dB(A); Active 80.1 dB(A)
   ▪ Uncertainty: ±3.0 dB(A)



• Dimensions & Weight:
   ▪ Height: 51.8″ (1316 mm)
   ▪ Length: 44.0″ (1118 mm)
   ▪ Width: 23.4″ (594 mm)
   ▪ Burnish Path Width: 20″ (508 mm)



• Battery & Runtime:
   ▪ Batteries: 3 × 12 V (114, 130, 225, or 234 Ah @ 20‑hr rate)
   ▪ Battery Compartment: 21.5″ × 15.25″ × 16″ (546 × 387 × 406 mm)



• Additional Information:
   ▪ Theoretical Coverage: 19,800 ft²/hr @ 2.5 mph (2″ overlap)
