DESCRIPTION

The Karcher KM 100/100 R Bp is a commercial walk-behind sweeper designed for efficient cleaning of large indoor and outdoor areas from 2,500 m² (≈ 26,910 sq ft). It features a robust dual dirt container system, a polyester round filter with automatic cleaning, and an adjustable floating main roller for thorough debris collection. The machine offers traction drive for forward and reverse movement, overhead sweeping principle, and a switchable sweeping function, making it ideal for car parks, warehouses, schools, industrial facilities, and retail centers. Two battery variants are available: wet batteries for maximum runtime and AGM batteries for lighter operation.

KEY APPLICATIONS

• Types of Environments
  Commercial buildings, public facilities, retail centers, industrial areas
• Floor Types
  Indoor and outdoor surfaces including car parks, production areas, and workshops
• Places
  Car parks, schools, service stations, car dealerships

FEATURES

• Polyester Round Filter
  Durable filter material with mechanical and automatic cleaning for consistent dust-free performance
• Floating Main Sweeper Roller
  Adapts to floor contours for optimal debris collection
• Side Brushes
  Adjustable and liftable, ensuring effective edge cleaning
• Coarse Dirt Flap
  Captures larger debris for uninterrupted sweeping
• Overhead Sweeping Principle
  Directs debris efficiently into the waste containers
• Traction Drive (Forward & Reverse)
  Smooth forward and safe reverse movement for precise operation
• Suction Volume Regulation
  Adjustable suction power for optimal cleaning on different surfaces
• Switchable Sweeping Function
  Option to disable sweeping for versatile operation
• Indoor & Outdoor Use
  Engineered for low-dust indoor cleaning and reliable outdoor performance
• Battery Indicator & Elapsed Time Counter
  Monitor battery status and track operating hours for maintenance scheduling

INCLUDED ACCESSORIES

• Polyester round filter
• Wheels, non-marking
• Filter cleaning system (manual and automatic)
• Floating main sweeper roller
• Suction volume regulation
• Coarse dirt flap
• Overhead sweeping principle
• Traction drive (forward & backward)
• Suction system
• Indoor & outdoor use capability
• Battery indicator
• Elapsed time counter
• Switchable sweeping function

TECHNICAL SPECIFICATIONS

• Dimensions & Weight
  • Length × Width × Height: 2006 × 1005 × 1343 mm (≈ 78.9 × 39.6 × 52.9 in)
  • Weight with wet batteries: 540 kg (≈ 1190 lb)
  • Weight with AGM batteries: 468.6 kg (≈ 1033 lb)
  • Transport Weight (wet batteries): 375 kg (≈ 827 lb)
  • Permissible Overall Weight: 660 kg (≈ 1455 lb)
• Performance & Speed
  • Driving / Cleaning Speed: 6 km/h (≈ 3.7 mph)
  • Climbing Ability: 15 %
  • Max Area Performance: 6,000 m²/h (≈ 64,583 sq ft/h)
  • Max Area Performance with 2 Side Brushes: 7,800 m²/h (≈ 83,958 sq ft/h)
  • Working Width Without Side Brushes: 700 mm (≈ 27.6 in)
  • Working Width with 1 Side Brush: 1000 mm (≈ 39.4 in)
  • Working Width with 2 Side Brushes: 1300 mm (≈ 51.2 in)
• Brush System
  • Roller Brush Diameter: 285 mm (≈ 11.2 in)
  • Roller Brush Width: 710 mm (≈ 28 in)
  • Side Brush Diameter: 450 mm (≈ 17.7 in)
• Waste & Filtration
  • Waste Container Volume: 100 L (≈ 26.4 gal)
  • Filter Surface Area: 6 m² (≈ 64.6 sq ft)
  • Nominal Vacuum (Suction): 12 mbar
  • Nominal Volume Flow (Suction): 50 l/s
• Motor & Electrical
  • Traction Drive Motor: 24 V / 750 W (wheel hub), total drive system 24 V / 2050 W
  • Fan & Roller Brush Motor: 24 V / 600 W, 3500 RPM
  • Side Brush Motor: 24 V / 100 W, 70 RPM
• Battery & Charging
  • Wet Battery Variant: 24 V 4 PzS 240 Ah, runtime approx. 2.5 h, charging time 10–15 h
  • AGM Battery Variant: Lighter weight, runtime slightly shorter, charging time similar
• Tyres & Brakes
  • Rear Tyre Size: 4.00–8, Air Pressure: 6 bar (≈ 87 psi)
  • Service Brake: Electronic
  • Parking Brake: Electrically operated disc brake, spring-loaded
• Operating Conditions
  • Temperature Range: -5 to +40 °C (23 to 104 °F)
  • Air Humidity: 20–90 % (non-condensing)
• Noise & Vibration
  • Sound Pressure Level: 75 dB(A)
  • Sound Power Level: 94 dB(A)
  • Hand-Arm Vibration: <2.5 m/s²
  • Seat Vibration: <0.5 m/s²
