DESCRIPTION

The Karcher Admiral XL Carpet Extractor delivers high-performance deep cleaning for large carpeted areas with SmartSpeed™ technology, low-moisture application, and an ergonomic, robust design. It boosts productivity by covering up to 3200 ft²/hr, while conserving resources and reducing operator fatigue. Operating at just 68 dB(A), it's ideal for noise-sensitive environments. Whether in hospitality, education, healthcare, or community spaces, the Admiral XL ensures faster drying, easy training, and consistently powerful results with a 120 V / 60 Hz power supply.

KEY APPLICATIONS:

• HOSPITALITY & EVENTS
  ▫ Deep-cleaning large carpets
  ▫ Low-moisture extraction for fast drying
  ▫ Quiet operation in guest areas



• EDUCATION & COMMUNITY
  ▫ Efficient carpet maintenance in classrooms and libraries
  ▫ Reduced noise for occupied spaces
  ▫ Resource-efficient cleaning for shared areas



• HEALTHCARE & COMMERCIAL
  ▫ Hygienic carpet sanitation in clinics and offices
  ▫ Quick turnaround in high-traffic zones
  ▫ Consistent deep cleaning for safety and appearance

FEATURES

• High-Performance Cleaning
  ▪︎ Delivers next-generation deep cleaning for large carpeted areas with superior results



• Boosts Productivity & Reduces Costs
  ▪︎ Engineered for efficiency to minimize operational time and expenses



• Ergonomic & Robust Design
  ▪︎ Built for operator comfort—reduces fatigue and supports long periods of use



• SmartSpeed™ Technology
  ▪︎ Provides real-time visual feedback for optimal extraction speed and consistent performance



• Resource-Efficient Operation
  ▪︎ Conserves water and detergent while simplifying operator training



• Low Moisture Application
  ▪︎ Shortens carpet drying time for quicker room turnaround in time-sensitive settings



• Versatile Use
  ▪︎ Ideal for Hospitality, Education, Healthcare, and Community facilities with extensive carpeting

TECHNICAL SPECIFICATIONS

• Dimensions & Weight
  ▪︎ Weight: 57.2 kg (126 lbs)
  ▪︎ Length: 83.8 cm (33 in)
  ▪︎ Width: 55.9 cm (22 in)
  ▪︎ Height: 114.3 cm (45 in)



• Mobility
  ▪︎ Wheels: 2 × 25 cm (10 in) diameter by 5.1 cm (2 in)



• Cleaning Components
  ▪︎ Vacuum Shoe: 46 cm (18 in), injection-molded plastic with spring-loaded down pressure
  ▪︎ Brush: 45.7 cm (18 in)
  ▪︎ Brush Speed: 1000 rpm
  ▪︎ Solution Spray: 4 quick-change jets



• Capacity
  ▪︎ Solution Tank: 45.5 L (12 gal)
  ▪︎ Recovery Tank: 35.01 L (9.25 gal)



• Electrical System
  ▪︎ Power: 115 V / 15 A / 60 Hz
  ▪︎ Power Cable: 12.7 m (50 ft), 14 gauge
  ▪︎ Vacuum Motor: 3-stage, 1 hp, 99 cfm (2.80 m³/min), Waterlift: 297 cm (117 in)
  ▪︎ Solution Pump: 100 PSI diaphragm style with internal bypass
